    wAP LTE kit

    The wAP LTE is a small weatherproof wireless access point with a built in cellular modem that supports 2G, 3G and 4G (LTE) connectivity. Connect to the wAP’s built-in 802.11b/g/n wireless and access the LTE network from your phone or any other wireless device. The wAP LTE also has one 10/100 Ethernet LAN port for your wired devices.

    LTE cards are connected to two internal antennas with u.FL connectors, so if you want, you can unplug the connectors and add your own external LTE antenna for larger coverage. Unit has the several powering options - 9-30v PoE-in by Ethernet port, DC jack and Automotive connector, very handy in mobile devices like car, bus or train.

    RBwAPR-2nD&R11e-LTE includes LTE modem that supports International LTE bands 1,2,3,7,8,20,38 and 40.

    Product specifications

    Details
    Product codeRBwAPR-2nD&R11e-LTE
    10/100 Ethernet ports1
    2G CategoryClass12
    3G CategoryR7 (21Mbps Downlinks, 5.76Mbps Uplink)
    Antenna gain dBi for 2.4 GHz2
    CPUQCA9531
    CPU core count1
    CPU nominal frequency650 MHz
    DC jack9-30 V
    Dimensions185 x 85 x 30 mm
    LTE Category4 (150Mbps Downlink, 50Mbps Uplink)
    LTE FDD bands1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz)
    LTE TDD bands38 (2600MHz) / 40 (2300MHz)
    License level4
    Max Power consumption8W
    MiniPCI-e slots1
    Number of DC inputs1
    Number of chains2
    Operating SystemRouterOS
    PCB temperature monitorYes
    PoE inPassive PoE
    Size of RAM64 MB
    Storage size16 MB
    Storage typeFLASH
    Tested ambient temperature-40°C .. +60°C tested
    Voltage MonitorYes
    Wireless 2.4 GHz chip modelQCA9531
    Wireless 2.4 GHz standards802.11b/g/n

    Wireless specifications

    2.4 GHz
    Transmit power (dBm)Receive Sensitivity
    1MBit/s22-96
    11MBit/s22-89
    6MBit/s20-93
    54MBit/s18-74
    MCS020-93
    MCS716-71

    Ethernet test results

    RBwAPR-2nD&R11e-LTEQCA9531 100M one port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)8.198.423.596.3173.688.9
    Bridging25 bridge filter rules8.198.423.596.370.936.3
    Routingnone (fast path)8.198.423.596.3160.882.3
    Routing25 simple queues8.198.423.596.390.846.5
    Routing25 ip filter rules8.198.423.596.343.222.1
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
