    SXT LTE kit

    1 029,60 kr
    Exkl. moms 1-3

    SXT 2G/3G/4G/LTE CPE, 9dBi 60 degree antenna, 2x Ethernet ports (one with PoE out), two SIM, 650MHz CPU, 64MB RAM, enclosure, PoE and PSU (RouterOS L3), International bands

    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    SXT LTE kit

    The SXT LTE kit (product code RBSXTR&R11e-LTE) is a device for remote locations that are within cellular network coverage. However, due to it’s professional LTE chip design and high gain antenna, it can provide connectivity for your building even where cell phones can’t.

    In comparison with our first generation model RBSXTLTE3-7, the SXT LTE kit is powered by faster CPU and supports not only LTE with more speeds, but also 2G and 3G, as well as much wider band range.

    The unit is equipped with two Ethernet ports (the second port has PoE-out functionality), so you can use it to power up another device. Unit is shipped with a 24 V power supply, but can support full range 18-57 V and is 802.3af/at compliant.

    The device has a built in high quality 2G/3G/4G/LTE Category 4 modem for speeds of up to 150 Mbit/s downlink and 50 Mbit/s uplink, as well as two Micro SIM slots for backup link.

    RBSXTR&R11e-LTE includes LTE modem that supports International LTE bands 1, 2, 3, 7, 8, 20, 38 and 40.


    Specifications

    Details
    Product codeRBSXTR&R11e-LTE
    ArchitectureMIPSBE
    CPUQCA9531
    CPU core count1
    CPU nominal frequency650 MHz
    Dimensions140 x 140 x 103 mm
    License level3
    Operating SystemRouterOS
    Size of RAM64 MB
    Storage size16 MB
    Storage typeFLASH
    Tested ambient temperature-40°C .. +60°C

    Powering

    Details
    Max Power consumption6W
    PoE in802.3af/at
    PoE outPassive PoE up to 57V
    PoE in input Voltage18-57 V
    Number of DC inputs1 (PoE-IN)

    Mobile

    Details
    2G CategoryClass12
    3G CategoryR7 (21Mbps Downlinks, 5.76Mbps Uplink)
    LTE Category4 (150Mbps Downlink, 50Mbps Uplink)
    LTE FDD bands1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz)
    LTE TDD bands38 (2600MHz) / 40 (2300MHz)

    Ethernet

    Details
    10/100 Ethernet ports2

    Peripherals

    Details
    Number of SIM slots2 Modem (Mini SIM)
    MiniPCI-e slots1

    Ethernet test results

    RBSXTR&R11e-LTEr2QCA9531 100M two port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)16.3197.947.0192.5297.6152.4
    Bridging25 bridge filter rules16.3197.947.0192.580.441.2
    Routingnone (fast path)16.3197.947.0192.5233.1119.3
    Routing25 simple queues16.3197.947.0192.5131.467.3
    Routing25 ip filter rules16.3197.947.0192.549.125.1
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    Included parts

    MikroTik
    RBSXTR&R11e-LTE
