    DynaDish 5

    1 963,20 kr
    Exkl. moms 1-3
    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The DynaDish 5 is a new 802.11ac outdoor device with an integrated 25dBi antenna. Compact in it’s design, it is a simple and completely integrated product with everything you need to quickly install a reliable point to point link.

    The DynaDish 5 is powered by a new 720MHz CPU from Qualcomm.

    Product specifications

    Details
    Product codeRBDynaDishG-5HacD
    CPU nominal frequency720 MHz
    CPU core count1
    Size of RAM128 MB
    10/100 Ethernet portsNone
    10/100/1000 Ethernet ports1
    MiniPCI slots0
    MiniPCI-e slots0
    Wireless chip modelQCA9882-BR4A-R
    Wireless standards802.11a/n/ac
    Number of USB ports0
    Power Jack0
    PoE in802.3at (only unshielded cable) or Passive PoE
    Supported input voltage11 V - 60 V
    PoE outNo
    Voltage MonitorYes
    PCB temperature monitorYes
    CPU temperature monitorNo
    DimensionsØ 404mm, height 175mm (without mount)
    Operating SystemRouterOS
    Operating temperature range-40C to +70C
    License level3
    Antenna gain DBI25
    Current MonitorNo
    CPUQCA9557-AT4A-R
    Max Power consumption16W
    SFP ports0
    SFP+ ports0
    Number of chains2
    Serial portNone

    Wireless specifications

    5 GHz
    TXRX
    6MBit/s31-96
    54MBit/s28-81
    MCS030-96
    MCS727-77
    MCS922-72

    wireless parameters may be limited in software, depending on your local regulatory limitations

    Included parts

    Performance test results

    RBDynaDishG-5HacDQCA9550 1G all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)162.41,972.2170.8699.6370.2189.5
    Bridging25 bridge filter rules162.41,972.2111.8457.999.951.1
    Routingnone (fast path)162.41,972.2317.41,300.1370.2189.5
    Routing25 simple queues162.41,972.2174.2713.5176.290.2
    Routing25 ip filter rules60.2731.162.8257.261.831.6
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
