    QRT-5 ac

    2 390,95 kr
    Exkl. moms 1-3
    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The QRT 5 ac is a rugged outdoor flat panel antenna, with a built in RouterBOARD. The device has a 24dBi antenna and a high power 5GHz wireless transmitter which now supports 802.11ac and is also backwards compatible with 802.11a/n.

    Inside is the high power RB911G-5HPacD dual chain wireless device (see separate brochure), with high performance, high output power wireless transmitter. It has a Gigabit Ethernet port, to fully utilise the benefit of 802.11ac high speed wireless.

    Easy to use and quick to deploy, QRT is ideal for longer point to point links at 802.11ac speeds.

    Product specifications

    Details
    Product codeRB911G-5HPacD-QRT
    CPU nominal frequency720 MHz
    CPU core count1
    Size of RAM128 MB
    10/100/1000 Ethernet ports1
    Wireless standards802.11a/n/ac
    Wireless chip modelQCA9882
    Power Jack1
    PoE inYes
    Supported input voltage8 V - 30 V
    Voltage MonitorYes
    PCB temperature monitorYes
    Dimensions309x320x50mm
    Operating SystemRouterOS
    Tested ambient temperature-30C to +70C
    License level4
    Antenna gain24
    CPUQCA9557
    Max Power consumption10.5W
    Number of chains2
    Storage typeNAND
    Storage size128 MB

    Wireless specifications

    5 GHz
    Transmit power (dBm)Receive SensitivityTransmit power (mW)
    6MBit/s31-961259
    54MBit/s27-81501
    MCS030-961000
    MCS727-77501
    MCS922-72158

    wireless parameters may be limited in software, depending on your local regulatory limitations

    Included parts

    Ethernet test results

    RB911G-5HPacD-QRTQCA9557 1G all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)81.2986.1234.9962.2477.7244.6
    Bridging25 bridge filter rules81.2986.1118.4485.0119.561.2
    Routingnone (fast path)81.2986.1234.9962.2408.2209.0
    Routing25 simple queues81.2986.1158.3648.4165.884.9
    Routing25 ip filter rules64.8786.970.4288.460.931.2
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
