    SXTsq 5 ac

    635,00 kr
    Exkl. moms 1-3
    SXTsq 5 ac Low-cost small-size 16dBi 5GHz dual chain integrated CPE/Backbone with AC support and Gigabit Ethernet
    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    SXTsq 5 ac

    The SXTsq 5 ac is a compact and lightweight outdoor 5Ghz 802.11ac wireless device with an integrated antenna, perfect for point-to-point links or as a CPE unit. The device includes one 10/100/1000 Mbit Ethernet port to fully utilize speeds that 802.11ac protocol provides.

    The SXTsq 5 ac retains a 16 dBi antenna like the SXT 5 ac, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner.

    - SXTsq 5 ac-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed. - SXTsq 5 ac (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).

    Specifications

    Details
    Product codeRBSXTsqG-5acD
    ArchitectureARM 32bit
    CPUIPQ-4018
    CPU core count4
    CPU nominal frequency716 MHz
    Dimensions129 x 129 x 34 mm
    License level3
    Operating SystemRouterOS
    Size of RAM256 MB
    Storage size16 MB
    Storage typeFLASH
    Tested ambient temperature-40 to 70° C

    Powering

    Details
    Max Power consumption7W
    PoE inPassive PoE
    PoE in input Voltage10-30 V
    Number of DC inputs1 (PoE-IN)

    Wireless

    Details
    Wireless 5 GHz number of chains2
    Wireless 5 GHz standards802.11ac
    Antenna gain dBi for 5 GHz16
    Wireless 5 GHz chip modelIPQ-4018

    Ethernet

    Details
    10/100/1000 Ethernet ports1

    Wireless specifications

    5 GHzTransmit (dBm)Receive Sensitivity
    6MBit/s25-96
    54MBit/s21-80
    MCS025-96
    MCS720-75
    MCS918-70

    Ethernet test results

    RBSXTsqG-5acDIPQ-4018 1G one port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)82.2998.2243.9999.01483.0759.3
    Bridging25 bridge filter rules82.2998.2215880.6217.5111.4
    Routingnone (fast path)82.2998.2243.9999.01489.5762.6
    Routing25 simple queues82.2998.2243.9999.0364.9186.8
    Routing25 ip filter rules82.2998.2155.1635.3151.377.5
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    Included parts
