Wireless wire
    • Wireless wire
    • Wireless wire
    • Wireless wire

    Wireless wire

    1 745,14 kr
    Exkl. moms 1-3
    Kvantitet
    Sista produkten i lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The Wireless Wire is a ground breaking solution which offers fiber speed and quality for a fraction of the price. This amazing kit replaces your Gigabit ethernet cable with two small devices that connect to each other over a 60 GHz wireless link.

    Simply point the included devices at one another and power them on, it will make a 1 Gbit full duplex link to instantly replace your cable - this is why we call it the Wireless Wire!

    The Wireless Wire makes secure AES encrypted 60 GHz wireless link that is not affected by the crowded WiFi spectrum, offering a stable and fast link for distances of 100 meters or more. The box includes two wAP60G devices that are already paired together, a wall mounting kit, straps for pole mounting and also a pair of table stands for using the devices indoors. The link will even work through most windows, depending on their material.

    Specifications

    Details
    Product codeRBwAPG-60ad kit
    ArchitectureARM 32bit
    CPUIPQ-4019-0-583MSP-TR-00-0
    CPU core count4
    CPU nominal frequency716 MHz
    Dimensions185 x 85 x 30 mm
    License level3
    Operating SystemRouterOS
    Size of RAM256 MB
    Storage size16 MB
    Storage typeFLASH

    Powering

    Details
    Max Power consumption5W
    PoE in802.3af/at
    PoE in input Voltage12-57 V
    Number of DC inputs2 (DC jack, PoE-IN)
    DC jack input Voltage12-57 V

    Ethernet

    Details
    10/100/1000 Ethernet ports1

    Ethernet test results

    RBwAPG-60ad kitIPQ-4019 1G one port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)81.2986.1234.9962.21483.0759.3
    Bridging25 bridge filter rules81.2986.1227.7932.7231.9118.7
    Routingnone (fast path)81.2986.1234.9962.21489.5762.6
    Routing25 simple queues81.2986.1234.9962.2375.7192.4
    Routing25 ip filter rules81.2986.1177.9728.7180.192.2
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
