wAP 60G RBwAPG-60ad-A AP L4
    • wAP 60G RBwAPG-60ad-A AP L4
    • wAP 60G RBwAPG-60ad-A AP L4

    wAP 60G RBwAPG-60ad-A AP L4

    1 460,00 kr
    Exkl. moms 1-3

    60 GHz Base Station with Phase array 60° beamforming Integrated antenna, 716 Mhz CPU, 256 MB RAM, PSU and PoE, RouterOS L4

    Kvantitet
    I lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The wAP 60G AP is weatherproof integrated 60 GHz wireless unit, that can be used indoors or outdoors in different scenarios - Base Station, Point-to-Point or CPE.

    The box includes a wall mounting kit, straps for pole mounting, power supply, PoE injector and also table stand for using the device indoors. Penetrates some windows depending on material.

    wAP 60G AP supports up to eight simultaneous clients on distances of 200m+.

    Specifications

    Details
    Product codeRBwAPG-60ad-A
    ArchitectureARM 32bit
    CPUIPQ-4019
    CPU core count4
    CPU nominal frequency716 MHz
    Dimensions185 x 85 x 30 mm
    License level4
    Operating SystemRouterOS
    Size of RAM256 MB
    Storage size16 MB
    Storage typeFLASH
    Tested ambient temperature-40°C .. +70°C

    Powering

    Details
    Max Power consumption5W
    PoE in802.3af/at
    PoE in input Voltage11-57 V
    Number of DC inputs2 (DC jack, PoE-IN)
    DC jack input Voltage11-57 V

    Ethernet

    Details
    10/100/1000 Ethernet ports1

    Ethernet test results

    RBwAPG-60ad-AIPQ-4019 1G one port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)81.2986.1234.9962.21483.0759.3
    Bridging25 bridge filter rules81.2986.1227.7932.7231.9118.7
    Routingnone (fast path)81.2986.1234.9962.21489.5762.6
    Routing25 simple queues81.2986.1234.9962.2375.7192.4
    Routing25 ip filter rules81.2986.1177.9728.7180.192.2
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    Included parts

    MikroTik
    m RBwAPG-60ad-A
    14 objekt
    2018-02-02
