SXTsq Lite60 with RouterOS L3
    • SXTsq Lite60 with RouterOS L3
    • SXTsq Lite60 with RouterOS L3

    SXTsq Lite60 with RouterOS L3

    882,13 kr
    Exkl. moms 1-3

    For use as 60GHz CPE in Point -to-Multipoint setups for connections up to 200m with wAP 60G AP, low cost version

    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The SXTsq Lite60 is a new model in our 60 GHz lineup. This is a low cost CPE unit for connecting to a 60 GHz AP, enabling you to build a cost effective point to multipoint setup in the clean 60 GHz wireless spectrum. Connect up to eight of these CPE units to a 60 GHz access point, such as our wAP60G AP.

    For links up to 200 meters, this is the best alternative for wireless connections where 2 and 5 GHz wireless space is crowded and unreliable, at a fraction of the cost. Also, it's possible to make point-to-point link with two SXTsq Lite60.

    Specifications

    Details
    Product codeRBSXTsq-60ad
    ArchitectureMIPSBE
    CPUQCA9531
    CPU core count1
    Dimensions129 x 129 x 34 mm
    License level3
    Operating SystemRouterOS
    Size of RAM64 MB
    Storage size16 MB
    Storage typeFLASH
    Tested ambient temperature-40°C .. +50°C

    Powering

    Details
    PoE inPassive PoE
    PoE in input Voltage12-30 V
    Number of DC inputs1 (PoE-IN)

    Ethernet

    Details
    10/100 Ethernet ports1

    Ethernet test results

    RBSXTsq-60adQCA9531 100M one port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)8.198.423.596.3173.688.9
    Bridging25 bridge filter rules8.198.423.596.370.936.3
    Routingnone (fast path)8.198.423.596.3160.882.3
    Routing25 simple queues8.198.423.596.390.846.5
    Routing25 ip filter rules8.198.423.596.343.222.1
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    Included parts

    MikroTik
    m RBSXTsq-60ad
