    wAP 60Gx3 RBwAPG-60ad-SA L4

    2 397,00 kr
    Exkl. moms 1-3

    60 GHz Base Station with Phase array 180° beamforming Integrated antenna, specially designed for Multipoint connections

    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The wAP 60Gx3 AP is a new access point model for the 60 GHz spectrum. Compared with the regular wAP 60G AP, this new model has a completely new antenna array, with support for a much wider angle of coverage and is optimized specifically for multipoint operation.

    The 96 antenna elements work with beamforming technology to provide connectivity for up to eight 60 GHz client devices at the same time, in a 180 degree field of view. Build a cost effective point to multipoint setup in the clean 60 GHz wireless spectrum, at a fraction of the cost.

    Two wAP 60Gx3 AP units can be used in point-to-point configurations as well.

    Specifications

    Details
    Product codeRBwAPG-60ad-SA
    ArchitectureARM 32bit
    CPUIPQ-4019
    CPU core count4
    CPU nominal frequency716 MHz
    Dimensions185 x 85 x 30 mm
    License level4
    Operating SystemRouterOS
    Size of RAM256 MB
    Storage size16 MB
    Storage typeFLASH
    Tested ambient temperature-40°C to 70°C

    Powering

    Details
    PoE in802.3af/at
    PoE in input Voltage20-57 V
    Number of DC inputs2 (DC jack, PoE-IN)
    DC jack input Voltage12-57 V
    Max power consumption11 W

    Ethernet

    Details
    10/100/1000 Ethernet ports1

    Ethernet test results

    RBwAPG-60ad-SAr2IPQ-4019 1G one port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)81,2986.1234,9962.21482,6759.1
    Bridging25 bridge filter rules81,2986.1227,7932.7231,9118.7
    Routingnone (fast path)81,2986.1235,1963.01421,8728.0
    Routing25 simple queues81,2986.1235,1963.0458,3234.6
    Routing25 ip filter rules81,2986.1234,9962.2236,8121.2
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    Included parts

    MikroTik
    m RBwAPG-60ad-SA
