    mAP

    372,00 kr
    Exkl. moms 1-3

    Dual-Chain 2.4GHz micro AP, 650MHz CPU, 64MB RAM, 2xEthernet, PoE out

    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The mAP (micro Access Point) is a tiny size wireless Dual-Chain 2.4GHz Access Point with full RouterOS capabilities. It is very portable, since it accepts power from a wide variety of sources - USB, Passive PoE and power jack. It also works as a PoE injector - the second Ethernet port provides up to 500mA of power to another device, for example, you can connect a SXT CPE device to it.

    Product specifications

    Details
    Product codeRBmAP2nD
    CPU nominal frequency650 MHz
    CPU core count1
    Size of RAM64 MB
    10/100 Ethernet ports2
    Wireless standards802.11b/g/n
    Wireless chip modelQCA9531
    Number of USB ports1
    Power Jack1
    802.3af supportno
    PoE in802.3af/at
    Supported input voltage11 V - 57 V
    PoE outYes
    Voltage MonitorYes
    PCB temperature monitorYes
    Dimensions68x68x19mm
    Operating SystemRouterOS
    Tested ambient temperature-10C to +70C tested
    License level4
    Antenna gain DBI1.2
    CPUQCA9531
    Max Power consumption5W
    USB Power ResetYes
    USB slot typemicroUSB type AB
    Number of chains2
    Storage typeFLASH
    Storage size16 MB

    Wireless specifications

    2.4 GHz
    Transmit power (dBm)Receive SensitivityTransmit power (mW)
    1MBit/s22-96158
    11MBit/s22-89158
    6MBit/s20-93100
    54MBit/s18-7463
    MCS020-93100
    MCS716-7140

    wireless parameters may be limited in software, depending on your local regulatory limitations

    Included parts

    Ethernet test results

    RBmAP2nDQCA9531 100M two port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)16.3197.947.1192.9173.688.9
    Bridging25 bridge filter rules16.3197.947.1192.956.729.0
    Routingnone (fast path)16.3197.947.1192.9160.882.3
    Routing25 simple queues16.3197.947.1192.972.637.2
    Routing25 ip filter rules16.3197.933.8138.434.617.7
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
    MikroTik
    m RBmAP-2nD
    8 objekt
    2019-09-27

    Nerladdning

    Produkt blad map

    mAP Produktblad

    Nerladdning (447.11k)
