NetMETAL 5 RB922UAGS dual chain
    • NetMETAL 5 RB922UAGS dual chain
    • NetMETAL 5 RB922UAGS dual chain
    • NetMETAL 5 RB922UAGS dual chain
    • NetMETAL 5 RB922UAGS dual chain
    • NetMETAL 5 RB922UAGS dual chain

    NetMETAL 5 RB922UAGS dual chain

    1 498,34 kr
    Exkl. moms 1-3

    NetMETAL 5 (720MHz CPU, 128MB RAM, 1xGigabit LAN, 1xSFP cage, 1xUSB, built-in 5Ghz 802.11ac 2x2 dual chain Super
    High Power wireless with two RP-SMA connectors, RouterOS L4, outdoor enclosure, POE, PSU, pole mount, rail mount)

    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    This RB922UAGS-5HPacD-NM version is equipped with a miniPCI-express slot a SIM slot for 3G/4G device or additional wireless card, a high power 2x2 dual chain 802.11ac wireless and two RP-SMA connectors for external antennas

    The NetMETAL is a completely new 802.11ac product in a waterproof metal enclosure. Its rugged design is made to withstand the toughest conditions, but at the same time is easy to use and can be opened and closed with one hand. The solid aluminum enclosure also works as a reliable heat-sink for its high output power radio.

    The NetMETAL is equipped with powerful 720Mhz CPU, 128MB RAM, one Gigabit Ethernet port, 802.11ac wireless, one SFP cage, USB, RP-SMA connectors for external antennas and RouterOS L4 license.

    Product specifications

    Details
    Product codeRB922UAGS-5HPacD-NM
    CPU nominal frequency720 MHz
    SFP DDMIyes
    CPU core count1
    Size of RAM128 MB
    10/100 Ethernet portsNone
    10/100/1000 Ethernet ports1
    MiniPCI slots0
    MiniPCI-e slots1
    Wireless chip modelQCA9882-BR4A-R
    Wireless standards802.11a/n/ac
    Number of USB ports1
    Power Jack0
    802.3af supportno
    Supported input voltage8 V - 30 V
    PoE inYes
    PoE outNo
    Voltage MonitorYes
    PCB temperature monitorYes
    CPU temperature monitorNo
    Dimensions143x247x48mm (PCB)
    Operating SystemRouterOS
    License level4
    Antenna gain DBINo
    Current MonitorNo
    CPUQCA9557-AT4A-R
    Max Power consumption19W
    SFP ports1
    SFP+ portsNone
    USB slot typeUSB type A
    Number of chains2
    Serial portNone

    Wireless specifications

    5 GHz
    TXRX
    6MBit/s31-96
    54MBit/s27-81
    MCS030-96
    MCS727-77
    MCS922-72

    Included parts

    Performance test results

    RB922UAGS-5HPacD-NMQCA9550 Max possible throughput
    ModeConfiguration64 byte512 byte1518 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)370.2189.5170.8699.6162.41,972.2
    Bridging25 bridge filter rules99.951.1111.8457.9162.41,972.2
    Routingnone (fast path)370.2189.5317.41,300.1162.41,972.2
    Routing25 simple queues176.290.2174.2713.5162.41,972.2
    Routing25 ip filter rules61.831.662.8257.260.2731.1
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
    MikroTik
    m RB922UAGS-5HPacD-NM
