The mANTBox is based on our new mANT sector antennas, but also has a wireless router built right in. Powered by the RB921 device, the mANTBox comes ready to use with everything included. The device uses a high speed 720MHz CPU and has a built in 802.11 ac/a/n wireless device with up to 31dBm output power.
Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr
All retur ska godkännas av oss sänd mail till info@shlab.se
The mANTBox is based on our new mANT sector antennas, but also has a wireless router built right in. Powered by the RB921 device, the mANTBox comes ready to use with everything included. The device uses a high speed 720MHz CPU and has a built in 802.11 ac/a/n wireless device with up to 31dBm output power.
mANTBox 19s comes with 19dBi 120 degree sector antenna.
We have two versions available - RB921GS-5HPacD-19S (International) and RB921GS-5HPacD-19S-US (USA). RB921GS-5HPacD-19S-US (USA) is factory locked for 5.17 - 5.25 GHz and 5.725 - 5.835 GHz frequencies. This lock can not be removed. RB921GS-5HPacD-19S (International) supports 5.17 - 5.835 GHz range.
Details | |
---|---|
Product code | RB921GS-5HPacD-19S |
CPU nominal frequency | 720 MHz |
CPU core count | 1 |
Size of RAM | 128 MB |
10/100/1000 Ethernet ports | 1 |
Wireless standards | 802.11a/n/ac |
Wireless chip model | QCA9882 |
Supported input voltage | 8 V - 30 V |
PoE in | Yes |
Voltage Monitor | Yes |
PCB temperature monitor | Yes |
Dimensions | 152 x 598 x 78 mm |
Operating System | RouterOS |
Operating temperature range | -30 + 70 C |
License level | 4 |
Antenna gain DBI | 19 |
Max Power consumption | 13W |
SFP ports | 1 |
Number of chains | 2 |
Storage type | NAND |
Storage size | 128 MB |
5 GHz | ||
---|---|---|
TX | RX | |
6MBit/s | 31 | -96 |
54MBit/s | 27 | -81 |
MCS0 | 30 | -96 |
MCS7 | 27 | -77 |
MCS9 | 22 | -72 |
wireless parameters may be limited in software, depending on your local regulatory limitations
