mANTBox 15s RouterBOARD 921GS-5HPacD-15S (EU)
    • mANTBox 15s RouterBOARD 921GS-5HPacD-15S (EU)
    • mANTBox 15s RouterBOARD 921GS-5HPacD-15S (EU)
    • mANTBox 15s RouterBOARD 921GS-5HPacD-15S (EU)

    mANTBox 15s RB921GS-5HPacD-15S (EU)

    1 460,80 kr
    Exkl. moms 1-3
    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The mANTBox is based on our new mANT sector antennas, but also has a wireless router built right in. Powered by the RB921 device, the mANTBox comes ready to use with everything included. The device uses a high speed 720MHz CPU and has a built in 802.11 ac/a/n wireless device with up to 31dBm output power.

    mANTBox 15s comes with 15dBi 120 degree sector antenna

    Product specifications

    Details
    Product codeRB921GS-5HPacD-15S
    CPU nominal frequency720 MHz
    CPU core count1
    Size of RAM128 MB
    10/100/1000 Ethernet ports1
    Wireless standards802.11a/n/ac
    Wireless chip modelQCA9882
    Power Jack1
    Supported input voltage9 V - 30 V
    PoE inYes
    Voltage MonitorYes
    PCB temperature monitorYes
    Dimensions140 x 348 x 82 mm
    Operating SystemRouterOS
    Operating temperature range-30 + 70 C
    License level4
    Antenna gain DBI15
    CPUQCA9557
    Max Power consumption13W
    SFP ports1
    Number of chains2
    Storage typeNAND
    Storage size128 MB

    Wireless specifications

    5 GHz
    TXRX
    6MBit/s31-96
    54MBit/s27-81
    MCS030-96
    MCS727-77
    MCS922-72

    wireless parameters may be limited in software, depending on your local regulatory limitations

    Included parts

    Performance test results

    RB921GS-5HPacD-15SQCA9557 1G all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)81.2986.1234.9962.2477.7244.6
    Bridging25 bridge filter rules81.2986.1118.4485.0119.561.2
    Routingnone (fast path)81.2986.1234.9962.2408.2209.0
    Routing25 simple queues81.2986.1158.3648.4165.884.9
    Routing25 ip filter rules64.8786.970.4288.460.931.2
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
