    MikroTik/OmniTIK 5 PoE ac

    1 280,00 kr
    Exkl. moms 1-3
    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    We are glad to introduce a significant upgrade to our popular OmniTik 5GHz access points!

    OmniTik 5 PoE ac features five Gigabit Ethernet ports and support for 802.11ac. It’s equipped with a powerful 720MHz CPU, 128MB RAM, high power 1,300mW 802.11a/n/ac Dual Chain wireless (support for AC as well as backwards compatible with regular 802.11a/n CPE) and comes with a new design weatherproof outdoor enclosure, two integrated 7.5dBi 5GHz omni antennas, a power supply, a PoE injector and a mounting kit.

    It also supports passive or standard 802.3at/af PoE input/output (12v-57v). Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! It can power 48V devices (like IP camera), if 48V input is used.

    - OmniTIK 5 PoE ac (International) supports 5150MHz-5875MHz range.

    Product specifications

    Details
    Product codeRBOmniTikPG-5HacD
    CPU nominal frequency720 MHz
    CPU core count1
    Size of RAM128 MB
    10/100/1000 Ethernet ports5
    Wireless standards802.11a/n/ac
    Wireless chip modelQCA9892
    Number of USB ports1
    PoE inYes
    PoE out802.3at
    Supported input voltage12 V - 57 V
    Voltage MonitorYes
    PCB temperature monitorYes
    Dimensions416 x 129 x 58 mm
    Operating SystemRouterOS
    License level4
    Antenna gain DBI7.5
    CPUQCA9557
    Max Power consumption18W
    USB Power ResetYes
    USB slot typeUSB type A
    Number of chains2
    Storage typeFLASH
    Storage size16 MB

    Wireless specifications

    5 GHz
    Transmit power (dBm)Receive SensitivityTransmit power (mW)
    6MBit/s31-961259
    54MBit/s27-81501
    MCS030-961000
    MCS727-77501
    MCS922-72158

    wireless parameters may be limited in software, depending on your local regulatory limitations

    Included parts

    Ethernet test results

    RBOmniTikPG-5HacDQCA9557 (720MHz) 1G all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)161.91966.1329.21348.4495.6253.7
    Bridging25 bridge filter rules124.31509.5124.1508.3126.965
    Routingnone (fast path)161.91966.1366.41500.8477.2244.3
    Routing25 simple queues161.91966.1181.4743192.798.7
    Routing25 ip filter rules67.6820.970.6289.261.831.6
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
