Cloud Router Switch CRS125-24G-1S-2HnD-IN
  • Cloud Router Switch CRS125-24G-1S-2HnD-IN

CRS125-24G-1S-2HnD-IN

2 157,40 kr
Exkl. moms 1-3

Cloud Router Switch 125-24G-1S-IN with Atheros AR9344 CPU, 128MB RAM, 24xGigabit LAN, 1xSFP, RouterOS L5, LCD panel, 2.4Ghz
802.11b/g/n wireless, desktop case, PSU

Kvantitet
Sista produkten i lager

  • Order vardag innan 12.00 skickas normalt samma dag med POSTNORD Order vardag innan 12.00 skickas normalt samma dag med POSTNORD
  • Alla returer ska godkännas innan via E-post info@shlab.se Alla returer ska godkännas innan via E-post info@shlab.se

Perfect SOHO gateway router, switch, 11n AP all in one box
• Ethernet, Fiber, or 4G (with optional USB modem)
gateway connection to Internet
• RouterOS gateway/firewall/VPN router
• up to twenty-five gigabit switch ports (1xSFP and 24xRJ45)
• 1000mW high power 2.4GHz 11n wireless AP

Cloud Router Switch is our new Smart Switch series. It is a fully
functional Layer 3 switch, and is powered by the familiar RouterOS.
All the specific Switch configuration options are available in a special
Switch menu, but if you want, ports can be removed from the switch
configuration, and used for routing purposes.
What’s more - this device has a built in 2.4GHz wireless access
point, this means you can have an AP, a router with any number of
ports, and a full wire speed smart switch, all in one device - ideal for
medium/small businesses and offices. It has 24 Gigabit ports, one SFP
cage, a microUSB port and a built in Wireless AP.

• Fully manageable L3 switch, full wire speed switching
• Wireless AP built in
• Configure ports as switch, or for routing
• If required, full RouterOS power right there



CPU Qualcomm Atheros AR9344 600 MHz
Memory 128MB
Ethernet 24x 10/100/1000 Mbit/s Gigabit Ethernet with Auto-MDI/X
SFP 1 SFP cages (Mini-GBIC; SFP module not included)
Expansion microUSB port, host and device mode
Storage 128MB Onboard NAND
Serial port One RJ45 serial port
Extras Reset switch; beeper; voltage and temperature monitoring; touchscreen LCD
Power options IEC C14 standard connector 110/220V
Board dimensions 285x145mmx45mm
Temperature -35C to +65C tested
OS MikroTik RouterOS v6, Level 5 license
Included CRS switch, power cable, usb cable

Wireless specifications

2.4 GHz
Transmit power (dBm)Receive SensitivityTransmit power (mW)
1MBit/s 29 -97 794
11MBit/s 28 -90 631
6MBit/s 30 -96 1000
54MBit/s 25 -76 316
MCS0 30 -96 1000
MCS7 23 -73 200

wireless parameters may be limited in software, depending on your local regulatory limitations

Included parts

Switching results

CRS125-24G-1S-2HnD-IN
Mode Configuration 64 byte 512 byte 1518 byte
kpps Mbps kpps Mbps kpps Mbps
Switching Non blocking Layer 2 throughput 37,202.4 19,047.6 5,874.1 24,060.2 2,031.9 24,674.9
Switching Non blocking Layer 2 capacity 37,202.4 38,095.2 5,874.1 48,120.3 2,031.9 49,349.8
Switching Non blocking Layer 1 throughput 37,202.4 25,000.0 5,874.1 25,000.0 2,031.9 25,000.0
Switching Non blocking Layer 1 capacity 37,202.4 50,000.0 5,874.1 50,000.0 2,031.9 50,000.0

Ethernet test results

CRS125-24G-1S-2HnD-IN AR9344 1G all port test
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 81.0 983.7 232.0 950.3 269.6 138.0
Bridging 25 bridge filter rules 81.0 983.7 86.0 352.3 87.6 44.9
Routing none (fast path) 81.0 983.7 210.0 860.2 226.9 116.2
Routing 25 simple queues 81.0 983.7 103.9 425.6 106.6 54.6
Routing 25 ip filter rules 56.8 689.8 59.6 244.1 60.5 31.0
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
  4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results




MikroTik
m crs125-24g-1s-2hnd-in
1 Produkt

Nerladdning

ProduktbladCRS125-24g-1s-2HnD

Nerladdning (217.58k)
