CRS109-8G-1S-2HnD-IN
    • CRS109-8G-1S-2HnD-IN

    CRS109-8G-1S-2HnD-IN

    1 462,40 kr
    Exkl. moms 1-3

    8x Gigabit Smart Switch, 1x SFP cage, LCD, 1000mW 802.11b/g/n Dual Chain wireless, 600MHz CPU, 128MB RAM, Metal desktop case, RouterOS L5, supports 10-57V, 802.3af/at compliant

    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    Cloud Router Switch 109-8G-1S-2HnD-IN is new "small size low cost" member of our CRS series. It comes with eight Gigabit Ethernet ports and high power 1000mW 2.4GHz wireless. Product supports 10-57V and is 802.3af/at compliant!

    Our CRS series combines the best features of a fully functional router and a Layer 3 switch, is powered by the familiar RouterOS. All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes.

    Product specifications

    Details
    Product codeCRS109-8G-1S-2HnD-IN
    SFP DDMIyes
    CPU nominal frequency600 MHz
    CPU core count1
    Size of RAM128 MB
    10/100 Ethernet portsNone
    10/100/1000 Ethernet ports8
    MiniPCI slots0
    MiniPCI-e slots0
    Wireless chip modelAR9344-DC3A-R
    Wireless standards802.11b/g/n
    Number of USB ports1
    Power Jack1
    802.3af supportyes
    PoE outNo
    PoE inYes
    Supported input voltage8 V - 57 V
    Voltage MonitorYes
    PCB temperature monitorYes
    CPU temperature monitorNo
    Dimensions200x145x45mm
    Operating SystemRouterOS
    Operating temperature range-35C to +65C tested
    License level5
    Antenna gain DBI2.5
    Current MonitorYes
    CPUAR9344-DC3A-R
    Max Power consumption13 W
    SFP ports1
    SFP+ portsNone
    USB slot typemicroUSB type AB
    Number of chains2
    Serial portRJ45

    Wireless specifications

    2.4 GHz
    TXRX
    1MBit/s29-97
    11MBit/s28-90
    6MBit/s30-96
    54MBit/s25-76
    MCS030-96
    MCS723-73

    wireless parameters may be limited in software, depending on your local regulatory limitations

    Switching results

    CRS109-8G-1S-2HnD-IN
    ModeConfiguration64 byte512 byte1518 byte
    kppsMbpskppsMbpskppsMbps
    SwitchingNon blocking Layer 2 throughput13,392.96,857.12,114.78,661.7731.58,883.0
    SwitchingNon blocking Layer 2 capacity13,392.913,714.32,114.717,323.3731.517,765.9
    SwitchingNon blocking Layer 1 throughput13,392.99,000.02,114.79,000.0731.59,000.0
    SwitchingNon blocking Layer 1 capacity13,392.918,000.02,114.718,000.0731.518,000.0

    Performance test results

    CRS109-8G-1S-2HnD-INAR9344 1G all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)81.0983.7232.0950.3269.6138.0
    Bridging25 bridge filter rules81.0983.786.0352.387.644.9
    Routingnone (fast path)81.0983.7210.0860.2226.9116.2
    Routing25 simple queues81.0983.7103.9425.6106.654.6
    Routing25 ip filter rules56.8689.859.6244.160.531.0
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
    MikroTik
    m crs109-2hnd tax
    10 objekt
    2019-01-25

    Nerladdning

    Produkt blad

    Nerladdning (471.48k)
