Cloud Router Switch CRS212-1G-10S-1S+
    • Cloud Router Switch CRS212-1G-10S-1S+

    CRS212-1G-10S-1S+

    2 090,00 kr
    Exkl. moms 1-3
    Kvantitet
    I lager

    • Order vardag innan 12.00 skickas normalt samma dag med POSTNORD Order vardag innan 12.00 skickas normalt samma dag med POSTNORD
    • Alla returer ska godkännas innan via E-post info@shlab.se Alla returer ska godkännas innan via E-post info@shlab.se

    Cloud Router Switch 212-1G-10S-1S+IN is new “small size low cost” member of our CRS series. It comes with one Gigabit Ethernet RJ45 port, ten SFP cages and one 10G SFP+ cage, as well as LCD panel and serial port (RJ45). Product includes indoor desktop case and power supply. Special ears are provided for mounting the unit in rack.

    Our CRS series combines the best features of a fully functional router and a Layer 3 switch, is powered by the familiar RouterOS. All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes.

    Product specifications

    Details
    Product codeCRS212-1G-10S-1S+IN
    CPU nominal frequency400 MHz
    CPU core count1
    Size of RAM64 MB
    10/100 Ethernet portsNone
    10/100/1000 Ethernet ports1
    MiniPCI slots0
    MiniPCI-e slots0
    Number of USB ports0
    Power Jack1
    PoE inNo
    PoE outNo
    Supported input voltage8 V - 30 V
    Voltage MonitorYes
    PCB temperature monitorYes
    CPU temperature monitorNo
    Dimensions200x144x47mm
    Operating SystemRouterOS
    Operating temperature range-35C to +65C tested
    License level5
    Current MonitorYes
    CPUQCA8519-AC2C
    Max Power consumption20W
    SFP ports10
    SFP+ ports1
    Serial portRJ45
    Suggested price$219.00

    Included parts

    Performance test results

    CRS212-1G-10S-1S+INQCA8519 Max possible throughput test
    ModeConfiguration64 byte512 byte1518 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)24.512.528.6117.126.7324.2
    Bridging25 bridge filter rules22.211.422.491.821.4259.9
    Routingnone (fast path)24.512.523.596.323.0279.3
    Routing25 simple queues21.010.822.491.819.6238.0
    Routing25 ip filter rules10.85.510.442.67.995.9
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
