Cloud Router Switch CRS326-24G-2S+RM
    • Cloud Router Switch CRS326-24G-2S+RM

    CRS326-24G-2S+RM

    2 007,20 kr
    Exkl. moms 1-3

    Cloud Smart Switch 326-24G-2S+RM with 24 x Gigabit Ethernet ports, 2x SFP+ cages, 1U rackmount case, PSU

    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    SwOS/RouterOS powered 24 port Gigabit Ethernet switch with two SFP+ ports, wire speed connectivity with several new switching features!

    It has “Dual boot” feature that allows you to choose which operating system you prefer to use, RouterOS or SwOS. If you prefer to have a simplified switch only OS with more switch specific features, use SwOS. If you are used to Winbox and would like the ability to use routing and other Layer 3 features on some ports in your CRS, boot and use RouterOS. You can select the desired operating system from RouterOS, from SwOS or from the RouterBOOT loader settings.

    It gives you all the basic functionality for a managed switch, plus more: allows to manage port-to-port forwarding, apply MAC filter, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields. SFP cage supports both 1.25 Gb SFP and 10 Gb SFP+ modules.

    Product specifications

    Details
    Product codeCRS326-24G-2S+RM
    10/100/1000 Ethernet ports24
    CPU98DX3236A1-BTD4C000
    CPU core count1
    CPU nominal frequency800 MHz
    Dimensions440 x 144 x 44 mm
    License level5
    Max Power consumption24W
    Operating SystemRouterOS / SwitchOS
    PoE inPassive PoE
    Power Jack1
    SFP+ ports2
    Serial portRJ45
    Size of RAM512 MB
    Storage size16 MB
    Storage typeFLASH
    Supported input voltage10 V - 30 V
    Tested ambient temperature-40°C .. +60°C

    Switching results

    CRS326-24G-2S+RM
    ModeConfiguration64 byte512 byte1518 byte
    kppsMbpskppsMbpskppsMbps
    SwitchingNon blocking Layer 2 throughput65,476.233,523.810,338.342,345.93,576.143,427.8
    SwitchingNon blocking Layer 2 capacity65,476.267,047.610,338.384,691.73,576.186,855.7
    SwitchingNon blocking Layer 1 throughput65,476.244,000.010,338.344,000.03,576.144,000.0
    SwitchingNon blocking Layer 1 capacity65,476.288,000.010,338.388,000.03,576.188,000.0

    Ethernet test results

    CRS326-24G-2S+RM98DX3236A1 all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)81.3987.3235962.6296151.6
    Bridging25 bridge filter rules81.3987.390.7371.590.946.5
    Routingnone (fast path)81.3987.3235962.6261.9134.1
    Routing25 simple queues81.3987.3112.6461.2111.557.1
    Routing25 ip filter rules59.8726.261.4251.559.530.5
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results.
    MikroTik
    m crs326-24g-2s+rm
    15 objekt
    2017-05-30
