Cloud Router Switch 317-1G-16S+RM/CRS317-1G-16S+RM
    • Cloud Router Switch 317-1G-16S+RM/CRS317-1G-16S+RM
    • Cloud Router Switch 317-1G-16S+RM/CRS317-1G-16S+RM

    CRS317-1G-16S+RM

    3 480,00 kr
    Exkl. moms 7-14

    The new Cloud Router Switch 317-1G-16S+RM is a rack-mountable manageable switch with Layer3 features, it has 16 SFP+ ports for high performance 10GbE connectivity and a 1GbE copper port for management.

    Mängdrabatter

    KvantitetRabattDu Sparar
    55%Upp till 870,00 kr
    Kvantitet
    Kan förbokas



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The new Cloud Router Switch 317-1G-16S+RM is a rack-mountable manageable switch with Layer3 features, it has 16 SFP+ ports for high performance 10GbE connectivity and a 1GbE copper port for management.

    CRS317-1G-16S+RM is powered by a next generation switching chip, giving you wire speed performance for all sixteen 10GbE ports with any Ethernet frame size. New features such as hardware-based Spanning Tree Protocol and Link Aggregation (LACP) provide enhanced protection and true professional performance for your demanding network.

    The unit has dual redundant power supplies and passive cooling case, so it’s completely silent - for hot environments two redundant fans will automatically keep the system cool if needed.

    Product specifications

    Details
    Product codeCRS317-1G-16S+RM
    10/100/1000 Ethernet ports1
    CPU98DX8216B0-BRR4C000
    CPU Threads count2
    CPU core count2
    CPU nominal frequency800 MHz
    CPU temperature monitorYes
    Dimensions443 x 224 x 44 mm
    License level6
    Max Power consumption42W
    Operating SystemRouterOS or SwitchOS
    SFP+ ports16
    Serial portRJ45
    Size of RAM1 GB
    Storage size16 MB
    Storage typeFLASH
    Tested ambient temperature-20 to 60° C

    Switching results

    CRS317-1G-16S+RM
    ModeConfiguration64 byte512 byte1518 byte
    kppsMbpskppsMbpskppsMbps
    SwitchingNon blocking Layer 2 throughput239,583.3122,666.737,828.9154,947.413,085.2158,906.4
    SwitchingNon blocking Layer 2 capacity239,583.3245,333.337,828.9309,894.713,085.2317,812.7
    SwitchingNon blocking Layer 1 throughput239,583.3161,000.037,828.9161,000.013,085.2161,000.0
    SwitchingNon blocking Layer 1 capacity239,583.3322,000.037,828.9322,000.013,085.2322,000.0

    Ethernet test results

    CRS317-1G-16S+RM98DX8216B0 all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)268.33258.2361.21479.5355.2181.9
    Bridging25 bridge filter rules98.41195.098.6403.99850.2
    Routingnone (fast path)254.43089.4309.81268.9315.4161.5
    Routing25 simple queues104.61270.3104.4427.6104.653.6
    Routing25 ip filter rules104.61270.3103.4423.5103.953.2
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
    MikroTik
    m CRS317-1G-16S+RM
    2020-10-30
