    CCR1072-1G-8S+

    24 872,00 kr
    Exkl. moms 7-14

    Our new flagship router, the CCR1072, is powered by a Tilera 72 core CPU, each core is clocked at 1GHz, and to fully utilise this power, the CCR1072 is equipped with eight independently connected 10G SFP+ ports.

    Kvantitet
    Kan Förbokas



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    Our new flagship router, the CCR1072, is powered by a Tilera 72 core CPU, each core is clocked at 1GHz, and to fully utilise this power, the CCR1072 is equipped with eight independently connected 10G SFP+ ports.

    The unit comes equipped with installed RouterOS L6, 16GB of built in ECC RAM, touchscreen color LCD, two removable (hotplug) power supplies for redundancy, smart card slot, microUSB, regular size USB, microSD and 2x M.2 slots for additional storage.

    Thanks to the unique 72 core processor and ports that are directly connected to the CPU, CCR1072 is capable of over 100 million packets per second throughput.

    Product specifications

    Details
    Product codeCCR1072-1G-8S+
    CPU nominal frequency1 GHz
    CPU core count72
    Size of RAM16 GB
    10/100 Ethernet portsNone
    10/100/1000 Ethernet ports1
    MiniPCI slots0
    MiniPCI-e slots0
    Number of USB ports2
    Memory Cards3
    Memory card typemicroSD, 2x M.2
    Power Jack0
    PoE inNo
    Supported input voltage12 V - 12 V
    PoE outNo
    Voltage MonitorYes
    CPU temperature monitorYes
    PCB temperature monitorYes
    Dimensions443x315x40mm
    Operating SystemRouterOS
    Operating temperature range-20C to +60C
    License level6
    Current MonitorYes
    CPUTLR4-07280DG-10CE
    Max Power consumption125W
    SFP ports0
    SFP+ ports8
    USB slot typeUSB type A
    Serial portRJ45

    Included parts

    Performance test results

    CCR1072-1G-8S+Tile 72 Core (1200Mhz, DDR1333) Max possible throughput
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)6,502.078,960.318,790.076,963.8119,047.660,952.4
    Bridging25 bridge filter rules6,130.574,448.88,192.733,557.310,339.55,293.8
    Routingnone (fast path)6,502.078,960.318,790.076,963.886,507.044,291.6
    Routing25 simple queues6,502.078,960.312,370.450,669.213,474.26,898.8
    Routing25 ip filter rules4,667.656,683.35,985.124,515.05,873.83,007.4
    CCR1072-1G-8S+Tile 72 Core (1200Mhz, DDR1600) Max possible throughput
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)6,502.078,960.318,790.076,963.8119,047.660,952.4
    Bridging25 bridge filter rules6,502.078,960.39,099.237,270.310,432.35,341.3
    Routingnone (fast path)6,502.078,960.318,790.076,963.894,668.448,470.2
    Routing25 simple queues6,502.078,960.313,500.055,296.013,683.57,006.0
    Routing25 ip filter rules5,247.663,726.96,125.525,090.06,104.03,125.2
    CCR1072-1G-8S+Tile 72 Core (1000Mhz, DDR1333) Max possible throughput
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)6,502.078,960.318,790.076,963.898,801.050,586.1
    Bridging25 bridge filter rules5,033.361,124.47,149.829,285.68,682.14,445.2
    Routingnone (fast path)6,502.078,960.318,790.076,963.873,061.037,407.2
    Routing25 simple queues6,502.078,960.310,980.344,975.311,368.25,820.5
    Routing25 ip filter rules4,125.650,101.35,051.520,690.94,999.02,559.5
    CCR1072-1G-8S+Tile 72 Core (1000Mhz, DDR1600) Max possible throughput
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)6,502.078,960.318,790.076,963.898,873.550,623.2
    Bridging25 bridge filter rules5,764.870,007.78,240.233,751.98,866.34,539.5
    Routingnone (fast path)6,502.078,960.318,790.076,963.876,201.039,014.9
    Routing25 simple queues6,502.078,960.311,073.545,357.111,444.45,859.5
    Routing25 ip filter rules4,664.756,648.15,200.321,300.45,321.02,724.4
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
