Cloud core router CCR1016
    • Cloud core router CCR1016

    CCR1016-12G

    5 430,00 kr
    Exkl. moms 1-3

    Cloud Core Router 1016-12G with Tilera Tile-Gx16 CPU (16-cores, 1.2Ghz per core), 2GB RAM, 12xGbit LAN, RouterOS L6, 1U
    rackmount case, PSU, LCD panel

    Kvantitet
    Sista produkten i lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    CCR1016 is an industrial grade super fast router with cutting edge 16 core CPU.
    If you need many millions of packets per second - Cloud Core Router is your best
    choice.
    The device is available with a 1U rackmount case (CCR1016-12G) or without the
    case as a board unit (CCR1016-12G-BU), has twelve Gigabit ethernet ports, a
    serial console cable and a USB port.
    The CCR1016-12G has two SODIMM slots, by default it is shipped with 2GB of
    RAM, but has no memory limit in RouterOS (will accept and utilize 16GB or more).

    • 16 core networking CPU, 1.2GHz clock per core
    • 12 Mbytes total on-chip cache
    • State of the art TILE GX architecture
    • 12x Gigabit ports, all directly connected to CPU
    • 1U rackmount case option
    • Color touchscreen LCD display
    • Up to 1.5 mpps throughput in regular mode
    • Up to 17.8 mpps throughput in fastpath mode (wire speed)
    • Up to 12 Gbps throughput with common RouterOS configurations
    CPUTilera Tile-Gx16 CPU (16-cores, 1.2Ghz per core)
    MemoryTwo SODIMM DDR slots, 2x 1GB installed (no hw or software max limit)
    EthernetTwelve 10/100/1000 Mbit/s Gigabit Ethernet with Auto-MDI/X
    ExpansionmicroUSB port, host and device mode
    Storage512MB Onboard NAND
    Serial portOne DB9 RS232C asynchronous serial port
    ExtrasReset switch; beeper; voltage, current and temperature monitoring; CPU fan
    Power optionsIEC C14 standard connector 110/220V and Passive PoE 24V. PSU included.
    Board dimensions355x145mm55mm
    TemperatureMax ambient temperature 50° @ 1.2GHz; 70° @ 1GHz CPU core frequency
    OSMikroTik RouterOS v6 (64bit), Level 6 license
    IncludedCCR1016-12G: router in a 1U rackmount case with LCD, PSU, power cable
    MikroTik
    m ccr-1016-12G
    1 Produkt
    2018-02-20
