CCR1016-12G

5 430,00 kr

Exkl. moms 1-3

Cloud Core Router 1016-12G with Tilera Tile-Gx16 CPU (16-cores, 1.2Ghz per core), 2GB RAM, 12xGbit LAN, RouterOS L6, 1U
rackmount case, PSU, LCD panel

Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr

All retur ska godkännas av oss sänd mail till info@shlab.se

Beskrivning
Produktdetaljer

CCR1016 is an industrial grade super fast router with cutting edge 16 core CPU.
If you need many millions of packets per second - Cloud Core Router is your best
choice.
The device is available with a 1U rackmount case (CCR1016-12G) or without the
case as a board unit (CCR1016-12G-BU), has twelve Gigabit ethernet ports, a
serial console cable and a USB port.
The CCR1016-12G has two SODIMM slots, by default it is shipped with 2GB of
RAM, but has no memory limit in RouterOS (will accept and utilize 16GB or more).

• 16 core networking CPU, 1.2GHz clock per core
• 12 Mbytes total on-chip cache
• State of the art TILE GX architecture
• 12x Gigabit ports, all directly connected to CPU
• 1U rackmount case option
• Color touchscreen LCD display
• Up to 1.5 mpps throughput in regular mode
• Up to 17.8 mpps throughput in fastpath mode (wire speed)
• Up to 12 Gbps throughput with common RouterOS configurations

CPU	Tilera Tile-Gx16 CPU (16-cores, 1.2Ghz per core)
Memory	Two SODIMM DDR slots, 2x 1GB installed (no hw or software max limit)
Ethernet	Twelve 10/100/1000 Mbit/s Gigabit Ethernet with Auto-MDI/X
Expansion	microUSB port, host and device mode
Storage	512MB Onboard NAND
Serial port	One DB9 RS232C asynchronous serial port
Extras	Reset switch; beeper; voltage, current and temperature monitoring; CPU fan
Power options	IEC C14 standard connector 110/220V and Passive PoE 24V. PSU included.
Board dimensions	355x145mm55mm
Temperature	Max ambient temperature 50° @ 1.2GHz; 70° @ 1GHz CPU core frequency
OS	MikroTik RouterOS v6 (64bit), Level 6 license
Included	CCR1016-12G: router in a 1U rackmount case with LCD, PSU, power cable
