CCR1016-12S-1S+

5 960,24 kr

Exkl. moms 7-14

Cloud Core Router 1016-12S-1S+ with Tilera Tile-Gx16 CPU (16-cores, 1.2Ghz per core), 2GB RAM, 12xSFP cages, 1xSFP+cage, RouterOS L6, 1U rackmount case, Dual PSU, LCD panel

Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr

All retur ska godkännas av oss sänd mail till info@shlab.se

Beskrivning
Produktdetaljer

CCR1016 is an industrial grade router with a cutting edge 16 core Tilera CPU. If you need many millions of packets per second - Cloud Core Router is your best choice.

This model has twelve SFP ports and one SFP+ port for 10G connectivity. It is available in a 1U rackmount case and also has a serial console port, a touchscreen LCD and a USB port.

The CCR1016-12S-1S+ comes with redundant power supplies and one RJ45 SFP 10/100/1000M copper module.

Specifications

Details
Product code	CCR1016-12S-1S+
Architecture	TILE
CPU	TLR4-01680
CPU core count	16
CPU nominal frequency	1.2 GHz
License level	6
Operating System	RouterOS
Size of RAM	2 GB
Storage size	128 MB
Storage type	NAND
Tested ambient temperature	-20°C to 60°C

Powering

Details
Number of AC inputs	2
AC input range	100-240
Max power consumption	47.5 W
Max power consumption without attachments	34 W

Fiber

Details
SFP DDMI	Yes
SFP ports	12
SFP+ ports	1

Peripherals

Details
Memory card type	microSD
Memory Cards	1
Serial port	RJ45
Number of USB ports	1
USB Power Reset	Yes
USB slot type	USB type A
Max USB current (A)	1

Other

Details
CPU temperature monitor	Yes
PCB temperature monitor	Yes
Mode button	Yes

Ethernet test results

CCR1016-12S-1S+r2		Tile 16 core max possible throughput test with SFP+ port
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	1625,2	19736,4	4698,3	19244,2	17857,1	9142,8
Bridging	25 bridge filter rules	1624,2	19724,3	2120,8	8686,8	2819,5	1443,6
Routing	none (fast path)	1625,5	19740,1	4609,8	18881,7	17857,1	9142,8
Routing	25 simple queues	1625,2	19736,4	2610,4	10692,2	2787,7	1427,3
Routing	25 ip filter rules	1043,5	12672,3	1253,4	5133,9	1316	673,8

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

IPsec test results

CCR1016-12S-1S+r2		CCR1016 series IPsec throughput
Mode	Configuration	1400 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Single tunnel	AES-128-CBC + SHA1	130.5	1461.6	123.4	505.4	115.4	59.1
256 tunnels	AES-128-CBC + SHA1	363.8	4074.6	413.8	1694.9	425.9	218.1
256 tunnels	AES-128-CBC + SHA256	357.6	4005.1	399.2	1635.1	425.9	218.1
256 tunnels	AES-256-CBC + SHA1	354.9	3974.9	399.2	1635.1	425.9	218.1
256 tunnels	AES-256-CBC + SHA256	348.0	3897.6	384.6	1575.3	403.8	206.7

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
