    RB960PGS-PB PowerBox PRO

    903,49 kr
    Exkl. moms 1-3
    Kvantitet
    I lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    PowerBox Pro

    The PowerBox Pro is an outdoor five gigabit ethernet port router with PoE output on four ports. Since the device has a waterproof outdoor case, you can mount it on a tower, or in other outdoor locations.

    It also supports passive or standard 802.3at/af PoE input/output. Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! It can power 802.3at and af mode B compatible devices, if 48-57 input voltage is used.

    The device has a SFP port for adding optical fiber connectivity. It is affordable, small and easy to use, but at the same time comes with a very powerful 800MHz CPU, capable of all the advanced configurations that RouterOS supports.

    Product specifications

    Details
    Product codeRB960PGS-PB
    10/100/1000 Ethernet ports5
    CPUQCA9557
    CPU core count1
    CPU nominal frequency800 MHz
    Dimensions125 x 52 x 225 mm
    License level4
    Max Power consumption9W
    Operating SystemRouterOS
    PCB temperature monitorYes
    PoE inPassive PoE
    PoE out802.3af/at
    Power Jack1
    SFP ports1
    Size of RAM128 MB
    Storage size16 MB
    Storage typeFLASH
    Supported input voltage12 V - 57 V
    Tested ambient temperature-40°C .. +70°C
    USB Power ResetYes
    Voltage MonitorYes

    Ethernet test results

    RB960PGS-PBQCA9557 (800Mhz) 1G all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)161.91,966.1401.51,644.5542.3277.7
    Bridging25 bridge filter rules143.21,739.0145.5596.0146.274.9
    Routingnone (fast path)161.91,966.1396.31,623.2521.7267.1
    Routing25 simple queues161.91,966.1217.2889.7216.0110.6
    Routing25 ip filter rules74.6905.978.0319.576.539.2
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
