    SXTsq Lite5

    474,28 kr
    Exkl. moms 2-3

    Low-cost small-size 16dBi 5GHz dual chain integrated CPE/Backbone

    Kvantitet
    I Lager

      Leveransvillkor

    Vi använder DHL & Postnord för leveranser

    The SXTsq Lite5 is a compact and lightweight outdoor wireless device with an integrated antenna. Perfect for point to point links of up to 12 kilometers or as a CPE unit. It is compact, weatherproof and easy to mount. The SXTsq Lite5 retains a 16dBi antenna like the SXT Lite5, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner (see photos for comparison).

    The device can be mounted on horizontal and vertical poles and masts, but for precise alignment, separately available is the QuickMount Pro, which allows to adjust in every angle (see photo and related product).

    - SXTsq Lite5-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.

    - SXTsq Lite5 (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).

    Specifications

    Details
    Product codeRBSXTsq5nD
    ArchitectureMIPSBE
    CPUAR9344
    CPU core count1
    CPU nominal frequency600 MHz
    Dimensions129x129x34mm
    RouterOS license3
    Operating System RouterOS
    Size of RAM64 MB
    Storage size16 MB
    Storage typeFLASH
    MTBFApproximately 100'000 hours at 25C
    Tested ambient temperature-40°C to 70°C

    Powering

    Details
    Number of DC inputs1 (PoE-IN)
    Max power consumption6 W
    FAN countPassive
    PoE inPassive PoE
    PoE in input Voltage10-30 V

    Wireless specifications

    Details
    Wireless 5 GHz Max data rate300 Mbit/s
    Wireless 5 GHz number of chains2
    Wireless 5 GHz standards802.11a/n
    Antenna gain dBi for 5 GHz16
    Wireless 5 GHz chip modelAR9344
    Wireless 5 GHz generationWi-Fi 4

    Ethernet

    Details
    10/100 Ethernet ports1

    Certification & Approvals

    Details
    CertificationCE, FCC, IC, EAC, ROHS
    IPIP54

    Wireless specifications

    5 GHzTransmit (dBm)Receive Sensitivity
    6MBit/s25-96
    54MBit/s20-80
    MCS025-96
    MCS719-75

    Included parts

    The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..

    RBSXTsq5nD
    46 st
