- På rea!
MikroTik/OmniTik UPA-5HnD
492,92 kr
Exkl. moms 1-3
Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr
All retur ska godkännas av oss sänd mail till info@shlab.se
OmniTIK is a weatherproof outdoor AP with dual-polarized omni antennas - the perfect companion for our SXT, or for any other 5GHz 802.11a/n standard device.
Weatherproof, durable and ready to use. It has five 10/100 Ethernet ports, PoE support and a built-in 400mW 802.11a/n wireless radio. It supports Nv2 TDMA technology with up to 200Mbit aggregate throughput.
LED signal indicators on it’s back are fully customisable, show Ethernet activity or wireless signal - or any other information from RouterOS. The USB port gives the ability to connect a 3G modem or a storage drive.
The OmniTIK UPA also features power output on it’s ethernet ports. Ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters to worry about.
Product specifications
| Details | |
|---|---|
| Product code | RBOMNITIKUPA5HnD |
| CPU speed | 400MHz |
| Antenna gain | 7.5dBi |
| TX power | 26dBm |
| Current Monitor | No |
| RAM | 32MB |
| Architecture | MIPS-BE |
| LAN ports | 5 |
| Gigabit | No |
| MiniPCI | 0 |
| Integrated Wireless | Yes |
| Wireless standards | 802.11an |
| USB | Yes |
| Memory Cards | No |
| Power Jack | No |
| 802.3af support | No |
| PoE | 8-30V, Supports PoE output on ports 2-5. Max current 500mA per port |
| Voltage Monitor | No |
| PCB temperature monitor | No |
| CPU temperature monitor | No |
| Dimensions | 368x125x55mm |
| Operating System | RouterOS |
| Temperature range | -30 .. +70C |
| RouterOS License | Level 4 |
Ethernet throughput
| RB OmniTIK U-5HnD @400MHz (5 port test) | 64 byte frames | 512 byte frames | 1518 byte frames | |||||
|---|---|---|---|---|---|---|---|---|
| IP Firewall | Conntrack | Mode | Mbps | Fps | Mbps | Fps | Mbps | Fps |
| off | off | Bridging | 47.1 | 92000 | 358.4 | 87500 | 452.97 | 37300 |
| on | off | Routing | 37.68 | 73600 | 294.91 | 72000 | 452.97 | 37300 |
| on | off | Bridging | 35.48 | 69300 | 230.2 | 56200 | 446.9 | 36800 |
| on | on | Routing | 28.42 | 55500 | 222.41 | 54300 | 445.68 | 36700 |
| on | on | Bridging | 18.94 | 37000 | 149.5 | 36500 | 425.04 | 35000 |
- Notes:
- All throughput tests done with Xena Networks specialized test system and RouterOS v5, according RFC2544, with Ethernet frame sizes 64, 512, 1518 bytes.
Each board is tested with specified number of Ethernet interfaces, to ensure optimal load on hardware. - Values in Italics indicate that the maximum possible throughput was reached, limited only by ethernet ports themselves.
