RB711-5Hn (RouterOS L3) med MMCX
122,50 kr
Exkl. moms 1-3
Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr
All retur ska godkännas av oss sänd mail till info@shlab.se
The RB711 is a small CPE type wireless router with an integrated 5GHz 802.11n 1x1 MIMO wireless card.
The integrated 5GHz 802.11a/n wireless card is capable of up to 22dBm transmit power output. It has built in 16kV ESD protection on the RF port.
This is a compact and easy to use solution for building your own CPE unit with a custom case and antenna
| Details | |
|---|---|
| Product code | RB711-5Hn |
| CPU speed | 400MHz |
| TX power | 22dBm |
| Current Monitor | No |
| RAM | 32MB |
| Architecture | MIPS-BE |
| LAN ports | 1 |
| Gigabit | No |
| MiniPCI | 0 |
| miniPCI-e | 0 |
| Integrated Wireless | Yes |
| Wireless standards | 802.11 a/n |
| USB | 0 |
| Power Jack | No |
| 802.3af support | No |
| PoE | 8-30V |
| Voltage Monitor | No |
| Temperature sensor | No |
| Dimensions | 105x105mm |
| Operating System | RouterOS |
| RouterOS License | Level3 |
Ethernet throughput
| RB711-5Hn @400MHz (1 port test) | 64 byte frames | 512 byte frames | 1518 byte frames | |||||
|---|---|---|---|---|---|---|---|---|
| IP Firewall | Conntrack | Mode | Mbps | Fps | Mbps | Fps | Mbps | Fps |
| off | off | Bridging | 49.66 | 97000 | 99.53 | 24300 | 99.95 | 8230 |
| on | off | Routing | 34 | 66400 | 99.53 | 24300 | 99.95 | 8230 |
| on | off | Bridging | 30.77 | 60100 | 99.53 | 24300 | 99.95 | 8230 |
| on | on | Routing | 25.6 | 50000 | 99.53 | 24300 | 99.95 | 8230 |
| on | on | Bridging | 18.02 | 35200 | 99.53 | 24300 | 99.95 | 8230 |
- Notes:
- All throughput tests done with Xena Networks specialized test system and RouterOS v5, according RFC2544, with Ethernet frame sizes 64, 512, 1518 bytes.
Each board is tested with specified number of Ethernet interfaces, to ensure optimal load on hardware. - Values in Italics indicate that the maximum possible throughput was reached, limited only by ethernet ports themselves.
