mANT30 PA
    • mANT30 PA

    mANT30 PA

    1 268,00 kr
    Exkl. moms 1-3
    Kvantitet
    Sista produkten i lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    mANT30 PA

    mANT30 is a professional class 5 GHz 30dBi dish antenna, built to the highest industry standards. Built to seamlessly accomodate our Basebox series products, but can be used for any pole mounted wireless device due to the adequate length of the included FlexGuide cable.

    Two antennas are available, with a standard type mount (MTAD-5G-30D3), and with a precision alignment mount (MTAD-5G-30D3-PA). The antennas come packaged with all necessary accessories and cables.

    Note: Basebox wireless device pictured for illustrative purposes. It is not included

    Product specifications

    Details
    Product codeMTAD-5G-30D3-PA
    Antenna gain DBI30dbi
    Frequency Range4.7-5.875 GHz
    PolarizationVertical and Horizontal
    Beamwidth3 deg
    VSWR≤ 1.4 typ, ≤ 1.8 max
    Port to Port Isolation>40dB min
    Front-to-Back Ratio>30 dB
    Cross Polarization>40 dB
    Power Rating100W
    Impedance50 ohms
    Elevation adjustment range+/- 15 deg
    Diameter x Depth70 x 45cm (27.5 x 17.8in)
    Weight5.7kg (12.6 lbs)
    ReflectorAluminum
    Outdoor RatingETSI EN 300 019-2-4
    StandardsEN 302 326 DN1, DN2, DN3, DN5
    Wind Survivability201kph (125mph)
    Wind Load (125 mph)181.4kg (400 lbs)
    Operating Temperature-50°C to 80°C(-49°F to 158°F)
    Pole Mount Diameter Range3 to 10cm (1.2 to 3.9in)
    Connector2x RP-SMA Female (outside thread)
    Packaged size73x73x20cm (29x29x8in)
    Packaged weight8.4 kg (18,5)
    MikroTik
    m MTAD-5G-30D3-PA
