MikroTik/RouterBOARD RB3011UiAS-RM med 1U racklåda och nätdel
    • MikroTik/RouterBOARD RB3011UiAS-RM med 1U racklåda och nätdel
    • MikroTik/RouterBOARD RB3011UiAS-RM med 1U racklåda och nätdel

    RB3011UiAS-RM med 1U racklåda och nätdel

    1 522,58 kr
    Exkl. moms 1-3
    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The RB3011 is a new multi port device, our first to be running an ARM architecture CPU for higher
    performance than ever before. The RB3011 has ten Gigabit ports divided in two switch groups, an
    SFP cage and for the first time a Superspeed full size USB 3.0 port, for adding storage or an external
    3G/4G modem.
    RB3011UiAS-RM
    Unit comes with 1U rackmount enclosure, a touchscreen LCD panel, a serial console port and
    PoE output functionality on the last Ethernet port.

    Specifications

    Product codeRB3011UiAS-RM
    CPU nominal frequency1.4 GHz
    CPU core count2
    Size of RAM1 GB
    10/100/1000 Ethernet ports10
    Switch chip modelQCA8337-AL3C-R
    Power Jack1
    PoE inYes (passive only)
    PoE outYes (port 10)
    Supported input voltage10 V - 30 V
    Voltage MonitorYes
    PCB temperature monitorYes
    Dimensions443x92x44mm
    License level5
    Operating SystemRouterOS
    CPUIPQ-8064
    Max Power consumption10W
    SFP port1
    USB slot typeUSB 3.0 type A
    Serial portRJ45

    Performance test results

    RB3011UiASAll port test RouterOS v6.30rc23
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)325.03,946.8939.83,849.41530.2783.5
    Bridging25 bridge filter rules325.03,946.8384.21,573.7348.6178.5
    Routingnone (fast path)325.03,946.8939.83,849.41,437.6736.1
    Routing25 simple queues325.03,946.8419.61,718.7419.7214.9
    Routing25 ip filter rules202.02,453.1204.1836.0188.496.5
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    IPsec test results

    RB3011UiAS-RMIPQ-8064 IPsec throughput
    ModeConfiguration1400 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Single tunnelAES-128-CBC + SHA169.9782.976.0311.375.438.6
    256 tunnelsAES-128-CBC + SHA170.5789.672.2295.772.437.1
    256 tunnelsAES-128-CBC + SHA25669.5778.472.2295.772.437.1
    256 tunnelsAES-256-CBC + SHA169.5778.472.0294.972.437.1
    256 tunnelsAES-256-CBC + SHA25668.9771.770.9290.472.437.1
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
    3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
