RB912UAG-2HPnD

    948,40 kr
    Exkl. moms 1-3
    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    RB912UAG-2HPnD

    The RB912UAG-2HPnD is very versatile device. It's small wireless router with an integrated 2.4GHz high power wireless card and an additional miniPCIe slot for 802.11 wireless, or 3G card. The Gigabit port helps to utilize the full potential of 802.11n wireless speeds.

    The integrated wireless card is capable of up to 1000mW output power. It has built in 16kV ESD protection on both the Ethernet and the MMCX ports

    Product specifications

    Details
    Product codeRB912UAG-2HPnD
    CPU nominal frequency600 MHz
    CPU core count1
    Size of RAM64 MB
    10/100 Ethernet ports0
    10/100/1000 Ethernet ports1
    MiniPCI slots0
    MiniPCI-e slots1
    Wireless chip modelAR9342-BL1A
    Wireless standards802.11b/g/n
    Number of USB ports1
    Memory CardsNo
    Power JackYes
    802.3af supportNo
    PoE8-30V DC
    Voltage MonitorYes
    PCB temperature monitorYes
    CPU temperature monitorNo
    Dimensions105x105mm
    Operating SystemRouterOS
    Temperature range-35C to +65C
    License levelL4
    Current MonitorNo
    TX power30dBi
    CPUAR9342-BL1A
    Max Power consumption14W at 24V
    SFP ports0
    USB slot typeUSB type A
    Number of chains2

    Performance test results

    RB912UAG-2HPnDGigabit port test (600Mhz)RouterOS v6.0rc5
    ModeConfiguration64 byte512 byte1518 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)269.6176.9232983.781995.3
    Bridging25 Bridge filter rules87.657.586364.681995.3
    Routingnone (fast path)226.9148.8210890.481995.3
    Routing25 Simple Queues)106.669.9103.9440.581995.3
    Routing25 IP filter rules60.539.759.6252.756.8698.0
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
