Rundstrålande 2,4GHz 7dBi vertikal

    666,00 kr
    Exkl. moms 1-3
    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    OD 24-7V is an omnidirectional antenna designed for the frequency of 2,4 GHz. OD 24-10V works in vertical polarization and has 7 dBi gain. It is a basestation antenna.

    OD 24-7V can be used for connections on short distances when height of a location requires the wide vertical beamwidth. The device can be used inside and outside buildings.

    This new design is characterized by low weight and good stability, which we achieved due to using a new type of mounting.

    Antenna comes with N Female connector per standard, and is equipped with U-bolt for mast mounting. It caries a 3 years warranty.



    Electrical Properties
    Frequency2400 – 2500 MHz
    Gain7 dBi
    Polarizationvertical
    Beamwidth deg horizontal360°
    Beamwidth deg vertical32°
    VSWR1.3
    Impedance50 Ohm
    Mechanical Properties
    Input ConnectorN-type / female
    Length392 x 22 mm
    Weight300g
    Radome materialUV-stable fiberglass
    ColorWhite
    ConstructionAll – weather operation
    Mounting Kit26 - 53 mm
    Cyberbajt
    cy od 24-7V
    11 objekt
