    CRS518-16XS-2XQ-RM

    15 056,15 kr
    Exkl. moms 2-3

    Cloud Router Switch 518-16XS-2XQ-RM with QCA9531 750 MHz CPU, 64 MB RAM, 98DX8525 switch chip, 2 x 100G QSFP28 ports, 16x 25G SFP28 ports, 1 x 100Mbit Eth port for management, USB type A, RouterOS L6, 1U rackmount enclosure,  dual hot-swap PSU, 4 x hot-swap fans15056,15

    Kvantitet
    Sista produkten i lager

      Leveransvillkor

    Vi använder DHL & Postnord för leveranser

    As our 100 Gigabit product family grows, the time has come to introduce a serious enterprise-level switch. A switch that is up for the challenge when the CRS504 port density is just not enough. Introducing the spectacular CRS518-16XS-2XQ!

    With 2x 100 Gigabit QSFP28 ports and 16x 25 Gigabit SFP28 ports, this is the perfect cost-effective addition to any enterprise network or data center. And with dual-redundant hot-swappable power supplies and fans, you won’t have to worry about unnecessary downtime.

    Here’s a real-life setup – similar to the one we’re using in our office:

    At the top, you could place two flagship CCR2216 routers to provide the main connectivity and routing. Then a blazing-fast 100 Gigabit connection leads to three CRS518 distribution level switches. This is where all the magic happens. The CRS518 switches connect every access level device to the main network, deal with traffic filtering, and network policy enforcement. And they handle all that with grace and dignity – thanks to the fantastic Marvell Prestera Aldrin2 switch-chip. The same chip you’ve seen in our flagship CCR2216 that did wonders with L3 Hardware Offloading.

    The 25-gigabit ports are backward compatible with 10 Gigabit and 1 Gigabit SFP devices. Mix and match as you need!

    The two hot-swap power supplies support a high input voltage range: 100-240V. The board itself uses up to 45W of power, while the total maximum power consumption goes up to 77W with all the attachments. It can be a bit more power-hungry than the CRS504, but you would be too if you had 16x 25-Gigabit ports, wouldn’t you?

    Our 100 Gigabit product family keeps growing: switches, routers, cables, and QSFP28 modules. If you want real speed and ultimate flexibility for the best price on the market – you want MikroTik!

    Nothing can stop this switch: it supports VLAN (802.1Q, 802.1ad), L3 hardware offloaded routing, ACL, LACP, MLAG, Jumbo frames, IGMP/MLD snooping, and so on. Keep your RouterOS up to date and enjoy the real power of CRS!

    Specifications

    Details
    Product codeCRS518-16XS-2XQ-RM
    ArchitectureMIPSBE
    CPUQCA9531
    CPU core count1
    CPU nominal frequency650 MHz
    RouterOS license6
    Operating SystemRouterOS
    Size of RAM64 MB
    Storage size16 MB
    Storage typeFLASH
    MTBFApproximately 200'000 hours at 25C
    Tested ambient temperature-40°C to 70°C

    Powering

    Details
    Number of AC inputs2
    AC input range100-240
    Frequency (Hz)47-63
    Max power consumption77 W
    Max power consumption without attachments45 W
    Cooling type4 fans

    Ethernet

    Details
    10/100 Ethernet ports1

    Fiber

    Details
    Number of 25G SFP28 ports16
    Number of 100G QSFP28 ports2

    Peripherals

    Details
    Serial console portRJ45
    Number of USB ports1
    USB slot typeUSB type A
    Max USB current (A)1

    Other

    Details
    CPU temperature monitorYes
    PCB temperature monitorYes
    Voltage MonitorYes

    Certification & Approvals

    Details
    CertificationCE, EAC, ROHS
    IP20

    Included parts

    The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
