    DynaDish 5

    1 296,37 kr
    Exkl. moms 2-3

    Dual chain 5GHz 802.11a/n/ac QCA9892, 128MB RAM, 720 MHz CPU, 25dBi antenna gain

    Kvantitet
    I Lager

      Leveransvillkor

    Vi använder DHL & Postnord för leveranser

    The DynaDish 5 is a new 802.11ac outdoor device with an integrated 25dBi antenna. Compact in it’s design, it is a simple and completely integrated product with everything you need to quickly install a reliable point to point link.

    The DynaDish 5 is powered by a new 720MHz CPU from Qualcomm.

    - RBDynaDishG-5HacD-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.

    - RBDynaDishG-5HacD (International) supports 5150-5875MHz range (Specific frequency range can be limited by country regulations).

    Specifications

    Details
    Product codeRBDynaDishG-5HacDr3
    ArchitectureMIPSBE
    CPUQCA9557
    CPU core count1
    CPU nominal frequency720 MHz
    DimensionsØ 404mm, height 175mm (without mount)
    RouterOS license3
    Operating System RouterOS
    Size of RAM128 MB
    Storage size16 MB
    Storage typeFLASH
    MTBFApproximately 200'000 hours at 25C
    Tested ambient temperature-40°C to 70°C

    Powering

    Details
    Number of DC inputs1 (PoE-IN)
    Max power consumption9 W
    FAN countPassive
    PoE in802.3af/at
    PoE in input Voltage11-60 V

    Wireless specifications

    Details
    Wireless 5 GHz Max data rate867 Mbit/s
    Wireless 5 GHz number of chains2
    Wireless 5 GHz standards802.11a/n/ac
    Antenna gain dBi for 5 GHz25
    Wireless 5 GHz chip modelQCA9892
    Wireless 5 GHz generationWi-Fi 5

    Ethernet

    Details
    10/100/1000 Ethernet ports1

    Other

    Details
    PCB temperature monitorYes
    Voltage MonitorYes

    Certification & Approvals

    Details
    CertificationCE, FCC, IC, EAC, ROHS
    IPIP54

    Wireless specifications

    5 GHzTransmit (dBm)Receive Sensitivity
    6MBit/s31-96
    54MBit/s28-81
    MCS030-96
    MCS727-77
    MCS922-72

    Included parts

    The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..

    RBDynaDishG-5HacD
    5 st
