    hAP Lite RB941-2nD-TC

    227,66 kr
    Exkl. moms 1-3
    Kvantitet
    I lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The home Access Point lite (hAP lite) is an ideal little device for your apartment, house or office.

    It supports button triggered WPS, for the convenience of not typing a complicated password when somebody wants to have wireless internet access, and can also be told to change to cAP mode and join a CAPsMAN centrally managed network by the push of a button.

    Of course, the device runs RouterOS with all the features, bandwidth shaping, firewall, user access control and many others.

    The hAP lite is equipped with a powerful 650MHz CPU, 32MB RAM, dual chain 2.4GHz onboard wireless, four Fast Ethernet ports and a RouterOS L4 license. USB power supply is included.

    Product specifications

    Details
    Product codeRB941-2nD-TC
    CPU nominal frequency650 MHz
    CPU core count1
    Size of RAM32 MB
    10/100 Ethernet ports4
    10/100/1000 Ethernet portsNone
    MiniPCI slots0
    MiniPCI-e slots0
    Wireless chip modelQCA9531-BL3A-R
    Wireless standards802.11b/g/n
    Number of USB ports0
    Power Jack1
    Supported input voltage5 V - 5 V
    PoE inNo
    PoE outNo
    Voltage MonitorNo
    PCB temperature monitorNo
    CPU temperature monitorNo
    License level4
    Antenna gain DBI1.5
    Current MonitorNo
    CPUQCA9531-BL3A-R
    Max Power consumption3W
    SFP portsNone
    SFP+ portsNone
    Number of chains2
    Serial portNone

    Wireless specifications

    2.4 GHz
    TXRX
    1MBit/s22-96
    11MBit/s22-89
    6MBit/s20-93
    54MBit/s18-74
    MCS020-93
    MCS716-71

    Performance test results

    RB941-2nDQCA9531 100M 4 port test
    ModeConfiguration64 byte512 byte1518 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)173.688.994.0385.032.5394.8
    Bridging25 bridge filter rules56.729.056.1229.832.5394.8
    Routingnone (fast path)160.882.394.0385.032.5394.8
    Routing25 simple queues72.637.263.7260.932.5394.8
    Routing25 ip filter rules34.617.733.8138.432.5394.8
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
    MikroTik
    m rb941-2nD-TC
    9 objekt
    2015-09-21
