    cAP lite

    262,00 kr
    Exkl. moms 1-3

    Low-cost dual-chain 2.4GHz AP with wall and ceiling enclosure

    Kvantitet
    I Lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    The cAP lite is a tiny access point device, perfect for public locations and hospitality businesses like hotels, airports, shopping malls etc. Included with the product are two different casings, which can easily be swapped out, or, if you really like to fit the design with the environment, we are providing 3D printer friendly design files.

    The cAP lite supports 802.11b/g/n and can be powered by power over ethernet. It’s a perfect companion for the MikroTik CAPsMAN (controlled AP system manager), allowing you to control all your AP devices from one central location. The cAP lite can also be used as a stand alone access point with the full potential of RouterOS.

    Product specifications

    Details
    Product codeRBcAPL-2nD
    CPU nominal frequency650 MHz
    CPU core count1
    Size of RAM64 MB
    10/100 Ethernet ports1
    Wireless standards802.11b/g/n
    Wireless chip modelQCA9533
    Supported input voltage5 V - 60 V
    PoE in802.3af/at
    DimensionsWall case: 88 x 52 x 20 mm Ceiling case: ⌀88 mm x 20 mm
    Operating SystemRouterOS
    Tested ambient temperature-40°C .. +70°C
    License level4
    Antenna gain DBI1.5
    CPUQCA9533
    Max Power consumption4W
    Number of chains2
    Storage typeFLASH
    Storage size16 MB

    Wireless specifications

    2.4 GHz
    Transmit power (dBm)Receive SensitivityTransmit power (mW)
    1MBit/s22-96158
    11MBit/s22-89158
    6MBit/s20-93100
    54MBit/s18-7463
    MCS020-93100
    MCS716-7140

    wireless parameters may be limited in software, depending on your local regulatory limitations

    Included parts

    Ethernet test results

    RBcAPL-2nDQCA9533 100M one port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)8.198.423.596.3173.688.9
    Bridging25 bridge filter rules8.198.423.596.370.936.3
    Routingnone (fast path)8.198.423.596.3160.882.3
    Routing25 simple queues8.198.423.596.390.846.5
    Routing25 ip filter rules8.198.423.596.343.222.1
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
    4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
