    CRS317-1G-16S+RM

    453,70 $
    Leverans inom 2-5 dagar

    Smart Switch, 1 x Gigabit LAN, 16 x SFP+ cages, Dual Core 800MHz CPU, 1GB RAM, 1U rackmount passive cooling case, Dual Power Supplies

    Kvantitet
    Finns i lager



    Leveransvillkor

    5991The new Cloud Router Switch 317-1G-16S+RM is a rack-mountable manageable switch with Layer3 features, it has 16 SFP+ ports for high performance 10GbE connectivity and a 1GbE copper port for management.

    CRS317-1G-16S+RM is powered by a next generation switching chip, giving you wire speed performance for all sixteen 10GbE ports with any Ethernet frame size. New features such as hardware-based Spanning Tree Protocol and Link Aggregation (LACP) provide enhanced protection and true professional performance for your demanding network.

    The unit has dual redundant power supplies and passive cooling case - for hot environments two redundant fans will automatically keep the system cool if needed.

    Specifications

    Details
    Product codeCRS317-1G-16S+RM
    ArchitectureARM 32bit
    CPU98DX8216
    CPU core count2
    CPU nominal frequency800 MHz
    Dimensions443 x 224 x 44 mm
    RouterOS license6
    Operating SystemRouterOS / SwitchOS
    Size of RAM1 GB
    Storage size16 MB
    Storage typeFLASH
    MTBFApproximately 200'000 hours at 25C
    Tested ambient temperature-20°C to 60°C

    Powering

    Details
    Number of AC inputs2
    AC input range100-240
    Max power consumption44 W
    FAN count2

    Ethernet

    Details
    10/100/1000 Ethernet ports1

    Fiber

    Details
    SFP+ ports16

    Peripherals

    Details
    Serial console portRJ45

    Other

    Details
    CPU temperature monitorYes

    Certification & Approvals

    Details
    CertificationCE, EAC, ROHS

    Included parts

    The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..

    CRS317-1G-16S+RM
    12 objekt

    Särskilda referenser

    ean13
    4752224002167
