    PANEL ANTENN 5GHZ 23DBI

    840,00 kr
    Exkl. moms 1-3
    Kvantitet
    Sista produkten i lager



    Order vardag före 12.00 går normalt samma dag med Postnord. Fri frakt över 4000kr



    All retur ska godkännas av oss sänd mail till info@shlab.se

    Key Features:

    • 23 dBi Directional Gain
    • Superior Performance
    • Ultra Low Sidelobes
    • Extremely High Data Throughput
    • Resistance to Interference From Other Networks
    • Great Impedance Matching
    • Horizontal or Vertical Polarization
    • Heavy-Duty Mounting Elements
    • 2 Years Warranty
    • Durability in Severe Weather Conditions



    Applications:

    • 5 GHz Band Wireless LAN
    • IEEE 802.11a WLAN Systems
    • RLAN
    • FWA



    Description:
    Panel antenna working in 5 GHz frequency with 23 dBi gain. Can be mounted for horizontal or vertical polarization. Antenna is built with very high quality materials, like a construction grade aluminium alloy, UVinhibited ABS, stainless stell and zinc galvanized U-bolt. Because of reduced sidelobes, antenna gives extremely high data throughput and keeps clear strong signal even in crowded radio enviroment. It´s resistant to interference from other networks and does not disrupt to other. Designed for operation under severe weather conditions. A proper materials allow operation in the salt water environment without corrosion. Heavy-duty mounting elements guarantees an easy elevation and tilt adjust as well as rock-stable operation. It can be used in client stations and as small base stations.

    Electrical Properties
    Frequency4.9 - 5.9 GHz
    Gain23 dBi
    Polarizationhorizontal or vertical
    Beamwidth deg horizontal10°
    Beamwidth deg vertical10°
    VSWR< 1.5
    Impedance50 O
    Sidelobe suppresion> 22 dB
    Front to back ratio> 25 dB
    Lighting protectionDC ground
    Mechanical Properties
    TechnologyMicrostrip
    Input ConnectorN-type female
    Dimensions350x330x36 mm / 13x13x1.4"
    Weight1.35 kg / 3 lbs
    Radome materialUV – inhibited ABS
    ColorWhite
    Base materialHigh quality aluminium alloy
    ConstructionAll – weather operation
    Mounting Kit50.8 mm / 2"
